LONGi
36-Panel Pallet | LONGi Hi-MO 7 610W N-Type Bifacial Panels | LR7-72HGD-610M
In stock
Pickup by appointment in Calgary · Shipping calculated at checkout
Product details
36-Panel Pallet of LONGi Hi-MO 7 610W Bifacial Solar Modules
This full pallet contains 36 LONGi LR7-72HGD-610M Hi-MO 7 bifacial dual-glass modules with 21.96kW of rated front-side capacity. The utility-format module uses LONGi HPDC cell technology, a 144 half-cell layout and high bifaciality for commercial, agricultural, industrial and engineered ground-mount projects.
Verified Pallet Summary
| Module model | LR7-72HGD-610M |
|---|---|
| Rated power | 610W per module |
| Quantity | 36 modules |
| Total front-side capacity | 21.96kW |
| Technology | LONGi Hi-MO 7 HPDC bifacial, dual glass |
| Cell layout | 144 half cells, 6 × 24 |
| Module efficiency | 22.6% |
| Open-circuit voltage, Voc | 52.44V |
| Short-circuit current, Isc | 14.65A |
| Maximum-power voltage, Vmp | 44.34V |
| Maximum-power current, Imp | 13.76A |
| Maximum system voltage | 1500V DC |
| Maximum series fuse | 30A |
| Power tolerance | 0 to +3% |
| Bifaciality | 80% ±5% |
| Pmax temperature coefficient | -0.280%/°C |
| Voc temperature coefficient | -0.230%/°C |
| Isc temperature coefficient | +0.045%/°C |
| Operating temperature | -40°C to +85°C |
| Dimensions | 2382 × 1134 × 30mm |
| Weight | 33.5kg per module |
| Approximate net module weight | 1,206kg for 36 modules, excluding pallet and packaging |
| Junction box | IP68, three diodes |
| Output cable | 4mm²; +400mm / -200mm or ±1400mm, depending on production configuration |
| Glass | Dual 2.0mm semi-tempered glass |
| Front / rear static load | 5400Pa / 2400Pa |
| Product warranty | 12 years for materials and processing |
| Performance warranty | 30-year extra linear power output; 87.4% stated at year 30, subject to LONGi terms |
Commercial Advantages
- High wattage per module can reduce total panel, clamp and racking count.
- Bifacial rear-side production can improve energy yield where ground reflectivity and array geometry permit.
- Low -0.280%/°C power coefficient supports stronger hot-weather output.
- Dual-glass construction and high mechanical loading suit demanding project environments.
What Is Included?
One factory pallet containing 36 solar modules. Racking, inverters, rapid-shutdown equipment, conductors, connectors, combiners, disconnects, freight unloading and installation are not included unless added to the quotation.
Freight and Receiving
This is an oversized, heavy freight shipment. The 36 modules alone weigh approximately 1,206kg; final packaged shipping weight and dimensions must be confirmed at order time. A forklift, loading dock or suitable unloading plan may be required. Inspect the pallet before signing the carrier receipt and document any visible damage immediately.
Electrical Design Notes
String length must be calculated using the site's minimum design temperature, module Voc temperature coefficient and the inverter's maximum DC voltage. Confirm MPPT current limits, conductor ampacity, overcurrent protection, rapid-shutdown requirements, grounding, racking compatibility and Canadian electrical-code requirements before purchase.
610W vs 605W Version
The 610W pallet provides 21.96kW from 36 modules. The 605W LR7-72HGD-605M pallet uses the same physical module platform but differs slightly in rated output and electrical characteristics. Choose based on inverter string design, available stock, project pricing and required DC capacity rather than wattage alone.
Official Datasheet
Download the official LONGi LR7-72HGD 585–620M datasheet
Frequently Asked Questions
Can these be used on a house?
Potentially, but the large 2382 × 1134mm format requires compatible racking, structural review, handling plans and local design approval.
Does bifacial mean the rear side always adds the same amount?
No. Rear-side gain depends on height, row spacing, ground reflectivity, shading and racking geometry.
Is the pallet price shipping-inclusive?
Freight is normally quoted separately because destination, access and unloading requirements vary.
Can the pallet be split?
This listing is priced and configured as a complete 36-module pallet. Ask about individual-module availability separately.
Why Buy from Solar World Canada?
- Canadian solar-system experience and practical product guidance.
- Calgary pickup by appointment and Canada-wide shipping coordination.
- Support selecting compatible batteries, inverters, racking and balance-of-system equipment.
- Project-focused recommendations instead of a one-size-fits-all product sale.
Availability note: Charge Solar currently marks the 610W model discontinued and points buyers toward in-stock alternatives. Confirm remaining stock before accepting payment.
Request a project quote: Send the installation postal code, array type, inverter preference, delivery access and required system size for an accurate equipment and freight quotation.
Full-Pallet Freight
This item ships as an intact manufacturer pallet. Actual freight is quoted separately based on destination, site access and unloading requirements. The additional $95 small-order pallet/protective-packaging fee does not apply.
